Configure MPLS-TE Shared Risk Link Group
Figure 39. Topology for SRLG
RTR2
Loopback Interface
|
#configure terminal |
Enter configure mode |
|
(config)#interface lo |
Enter the Interface mode for the loopback interface |
|
(config-if)#ip address 2.2.2.2/32 secondary |
Configure IP address on loopback interface |
|
(config-if)#commit |
Commit the transaction |
MPLS Interface
|
(config)#interface xe1 |
Enter the Interface mode |
|
(config-if)#ip address 22.1.1.2/24 |
Configure ip address on the interface |
|
(config-if)#label-switching |
Enable label switching on the interface |
|
(config-if)#exit |
Exit Interface mode and return to Configure mode. |
|
(config)#interface xe5 |
Enter the Interface mode |
|
(config-if)#ip address 30.1.1.2/24 |
Configure ip address on the interface |
|
(config-if)#label-switching |
Enable label switching on the interface |
|
(config-if)#exit |
Exit Interface mode and return to Configure mode. |
|
(config)#interface xe7 |
Enter the Interface mode |
|
(config-if)#ip address 11.1.1.2/24 |
Configure ip address on the interface |
|
(config-if)#label-switching |
Enable label switching on the interface |
|
(config-if)#commit |
Commit the transaction. |
OSPF
|
(config)#router ospf 1 |
Enter the Router OSPF mode |
|
(config-router)#router-id 2.2.2.2 |
Configure OSPF router ID |
|
(config-router)#network 2.2.2.2/32 area 0 |
Advertise loopback address in OSPF |
|
(config-router)#network 11.1.1.0/24area 0 |
Advertise network address in OSPF |
|
(config-router)#network 22.1.1.0/24 area 0 |
Advertise network address in OSPF |
|
(config-router)#network 30.1.1.0/24area 0 |
Advertise network address in OSPF |
|
(config-if)#commit |
Commit the transaction |
Global RSVP
|
(config)#router rsvp |
Enter the Router RSVP mode |
|
(config-if)#commit |
Commit the transaction |
RSVP Interface
|
(config)#interface xe1 |
Enter the Interface mode |
|
(config-if)#enable-rsvp |
Enable RSVP on the interface |
|
(config-if)#exit |
Exit Interface mode and return to Configure mode. |
|
(config)#interface xe5 |
Enter the Interface mode |
|
(config-if)#enable-rsvp |
Enable RSVP on the interface |
|
(config-if)#exit |
Exit Interface mode and return to Configure mode |
|
(config)#interface xe7 |
Enter the Interface mode |
|
(config-if)#enable-rsvp |
Enable rsvp on the interface |
|
(config-if)#commit |
Commit the transaction |
Global SRLG (Path Type: Forced)
|
(config)#router rsvp |
Enter the Router RSVP mode. |
|
config-router)#srlg-disjoint forced |
Configure SRLG path type forced |
|
(config-router)#commit |
Commit the transaction. |
Disjoint type “preferred” can be configured globally using the command srlg-disjoint preferred.
SRLG Interface
|
(config)#interface xe1 |
Enter the interface mode |
|
(config-if)#mpls traffic-eng srlg 11 |
Configure SRLG value in the interface |
|
(config-if)#exit |
Exit Interface mode and return to Configure mode |
|
(config)#interface xe7 |
Enter the Interface mode |
|
(config-if)#mpls traffic-eng srlg 11 |
Configure SRLG value in the interface |
|
(config-if)#exit |
Exit Interface mode and return to Configure mode |
|
(config)#interface xe5 |
Enter the Interface mode |
|
(config-if)#mpls traffic-eng srlg 30 |
Configure SRLG value in the interface |
|
(config-if)#commit |
Commit the transaction |
MPLS RSVP Path
|
(config)#rsvp-path path1 |
Configure MPLS-path |
|
(config-path)#11.1.1.3 strict |
Configure first hop for the path |
|
(config-path)#12.1.1.4 strict |
Configure second hop for the path |
|
(config-path)#exit |
Exit mpls-path mode and return to Configure mode |
|
(config)#rsvp-path sec-path1 |
Configure MPLS-path |
|
(config-path)#4.4.4.4 loose |
Configure loose path |
|
(config-path)#exit |
Exit mpls-path mode and return to Configure mode |
|
(config-path)#rsvp-path sec-path2 |
Configure MPLS-path |
|
(config-path)#4.4.4.4 loose |
Configure loose path |
|
(config-if)#commit |
Commit the transaction |
RSVP-TE Tunnel with Secondary Protection and SRLG Disjoint Type Forced:
|
#configure terminal |
Enter configure mode |
|
(config)#rsvp-trunk lsp1 |
Configure RSVP trunk |
|
(config-trunk)#primary path path1 |
Configure primary path |
|
(config-trunk)#secondary-priority 1 path sec-path1 |
Configure secondary path |
|
(config-trunk)#secondary-priority 1 srlg-disjoint forced |
Configure SRLG for secondary path |
|
(config-trunk)#secondary-priority 2 path sec-path2 |
Configure secondary path |
|
(config-trunk)#secondary-priority 2 srlg-disjoint forced |
Configure SRLG for secondary path |
|
(config-trunk)#to 4.4.4.4 |
Configure RSVP trunk destination address |
|
(config-if)#commit |
Commit the transaction |
Disjoint type preferred can be configured in rsvp-trunk secondary using the command "secondary-priority 2 srlg-disjoint forced.
RSVP-TE Tunnel with Fast Reroute Protection One-to-One
|
#configure terminal |
Enter configure mode |
|
(config)#rsvp-trunk lsp2 |
Configure RSVP trunk |
|
(config-trunk)#primary fast-reroute protection one-to-one |
Configure fast-reroute protection |
|
(config-trunk)#primary path path1 |
Configure primary path |
|
(config-trunk)#to 4.4.4.4 |
Configure RSVP trunk destination address |
|
(config-if)#commit |
Commit the transaction |
RSVP-TE Tunnel with Fast Reroute Protection Facility Backup
|
#configure terminal |
Enter configure mode |
|
(config)#rsvp-bypass bypass1 |
Configure rsvp bypass tunnel |
|
(config-bypass)#path path1 |
Configure path for bypass tunnel |
|
(config-bypass)#to 4.4.4.4 |
Configure destination address for tunnel |
|
(config-bypass)#exit |
Exit rsvp-bypass tunnel mode |
|
(config)#rsvp-trunk lsp3 |
Configure rsvp trunk |
|
(config-trunk)#primary fast-reroute protection facility |
Configure fast-reroute protection facility |
|
(config-trunk)#primary path sec-path1 |
Configure path |
|
(config-trunk)#to 4.4.4.4 |
Configure the destination of rsvp trunk |
|
(config-if)#commit |
Commit the transaction |
